M126/M127/M128 5-34 SM
Duplex feed 2
This test feeds a blank sheet of paper to the duplex paper stop position 2. This test can be run
using any of the supported paper sizes.
To run the Duplex Feed 2 Test:
1. Touch
to select "Duplex Feed 2" from DUPLEX TESTS. The power indicator blinks while
the paper is feeding, and the message "Duplex Feed 2 Feeding…" displays. The message
"Duplex Feed 2 Clear Paper" displays when the paper reaches the duplex paper stop position
2, and the power indicator turns on solid.
2. Remove the media from the duplex unit, and clear the message on the operator panel by
touching "Back" or pressing "Stop"
.
5.3.6 INPUT TRAY TESTS
Feed tests (input tray)
This test lets the technician observe the paper path as media is feeding through the machine. A
blank sheet of paper feeds through the machine as the laser turns off during this test. The only
way to observe the paper path is to open the lower front door that is used to access the envelope
or multipurpose feeder. The paper is placed in the output bin.
To run the Input Tray Feed Tests:
1. Touch
to select "Feed Tests" from INPUT TRAY TESTS.
2. Touch
to select the input source from the sources displayed on the Feed Tests menu. All
installed sources are listed.
3. Touch
to select either Single or Continuous.
 "Single"—feeds one sheet of media from the selected source.
 "Continuous"—media continues feeding from the selected source until "Stop"
is
pressed.
