Diagnostics Menu
SM 5-25 M126/M127/M128
System
Maintenance
5.3.2 REGISTRATION (PRINTER)
Print registration makes sure the printing is properly aligned on the page.
The settings available are:
Description Value Direction of change
Top Margin
-25 to +25
Each increment causes
approximately 4 pels shift (at
600dpi).
A positive change moves
the image down the page
and increases the top
margin. A negative change
moves the image up and
decreases the top margin.
Bottom Margin
-20 to +20
Each increment causes
approximately0.55 mm shift
in the bottom margin.
A positive change
compresses the image so
it appears to move down
the page, and a negative
change moves the image
up.
Left Margin -25 to +25
A positive change moves
the image right, and a
negative change moves
the image left. No
compression occurs.
