Transfer: Motor-Shift Type (Transfer with Shift Actuator) 3C-29
DTC Confirmation Procedure
1) Clear DTC using scan tool.
2) Select transfer switch to “4H” position and keep its position for 10 seconds. Similarly select transfer switch to “4H-
lock”, “N” and “4L-lock” position.
3) Check DTC.
Troubleshooting
Step Action Yes No
1 Was “4WD control system check” performed? Go to Step 2. Go to “4WD Control
System Check: Motor-
Shift Type (Transfer with
Shift Actuator)”.
2 Transfer switch circuit check
1) Disconnect transfer switch connector “G59” with ignition
switch OFF.
2) Check for proper connection to “G59-2”, “G59-3” and
“G59-4” terminals of transfer switch connector.
3) If connection is OK, measure voltage between “G59-2”,
“G59-3” or “G59-4” terminal of transfer switch connector
and vehicle body ground with ignition switch ON.
Is it 10 – 14 V?
Go to Step 3. Go to Step 4.
3 Transfer switch check
1) Check transfer switch referring to “Transfer Switch
Inspection: Motor-Shift Type (Transfer with Shift
Actuator)”.
Is switch in good condition?
Substitute a known-
good 4WD control
module and recheck.
Replace transfer switch.
4 Wire harness check
1) Disconnect connector from 4WD control module
connector “E91” with ignition switch OFF.
2) Check for shorted to ground in related circuits.
• Between “G59-2” terminal of transfer switch connector
and “E91-18” terminal of 4WD control module
connector
• Between “G59-3” terminal of transfer switch connector
and “E91-19” terminal of 4WD control module
connector
• Between “G59-4” terminal of transfer switch connector
and “E91-20” terminal of 4WD control module
connector
Are they in good condition?
Substitute a known-
good 4WD control
module and recheck.
Repair circuit.
To Next Page
