Automatic Transmission/Transaxle: 5A-9
NOTE
*1: For vehicle not equipped with engine diagnosis connector model (Except RH steering vehicle not
equipped with rear fog light model)
INPUT / OUTPUT
CONTROL
Accelerator effective position
Throttle position
Coolant temperature
Engine torque
Engine speed
A/C ON/OFF
Brake light switch
Vehicle speed
Cruise control signal
P/N mode switch
"3" position switch
Input shaft speed sensor
ATF temperature sensor
Output shaft speed sensor
4L/N switch
Torque reduction request
Shift switch
Lock-up control
Gear Shift control
4th gear inhibit control
Slope shift control
Cruise shift control
Slip control
Line pressre control
Torque control
Overrun control
Reverse control
Squirt control
Speed meter indicate
Output Input
Shift solenoid valve-A
Shift solenoid valve-B
Pressure control solenoid valve
TCC pressure control solenoid valve
Slip control signal *1
