Automatic Transmission/Transaxle: 5A-41
Poor 3 → O/D shift Malfunction of shift solenoid valve No.2 Inspect. If NG, replace.
Malfunction of output shaft speed
sensor
Inspect. If NG, replace.
Malfunction of transmission range
sensor
Inspect. If NG, replace.
Malfunction of “3” position switch Inspect. If NG, replace.
Malfunction of accelerator pedal position
sensor
Inspect referring to “DTC P0122: Throttle
Position Sensor (Main) Circuit Low: in Section
1A”, “DTC P0123: Throttle Position Sensor
(Main) Circuit High: in Section 1A”, “DTC
P0222: Throttle Position Sensor (Sub) Circuit
Low: in Section 1A” and “DTC P0223: Throttle
Position Sensor (Sub) Circuit High: in Section
1A”.
Malfunction of pressure control solenoid
valve
Inspect. If NG, replace valve body assembly.
Faulty valve body component Replace valve body assembly.
Poor O/D
→ 3 shift Malfunction of shift solenoid valve No.2 Inspect. If NG, replace.
Malfunction of output shaft speed
sensor
Inspect. If NG, replace.
Malfunction of “3” position switch Inspect. If NG, replace.
Malfunction of accelerator pedal position
sensor
Inspect referring to “DTC P0122: Throttle
Position Sensor (Main) Circuit Low: in Section
1A”, “DTC P0123: Throttle Position Sensor
(Main) Circuit High: in Section 1A”, “DTC
P0222: Throttle Position Sensor (Sub) Circuit
Low: in Section 1A” and “DTC P0223: Throttle
Position Sensor (Sub) Circuit High: in Section
1A”.
Malfunction of pressure control solenoid
valve
Inspect. If NG, replace valve body assembly.
Faulty valve body component Replace valve body assembly.
Poor 3
→ 2 shift Malfunction of shift solenoid valve No.1 Inspect. If NG, replace.
Malfunction of output shaft speed
sensor
Inspect. If NG, replace.
Malfunction of accelerator pedal position
sensor
Inspect referring to “DTC P0122: Throttle
Position Sensor (Main) Circuit Low: in Section
1A”, “DTC P0123: Throttle Position Sensor
(Main) Circuit High: in Section 1A”, “DTC
P0222: Throttle Position Sensor (Sub) Circuit
Low: in Section 1A” and “DTC P0223: Throttle
Position Sensor (Sub) Circuit High: in Section
1A”.
Faulty valve body component Replace valve body assembly.
Poor 2
→ 1 shift Malfunction of shift solenoid valve No.2 Inspect. If NG, replace.
Malfunction of output shaft speed
sensor
Inspect. If NG, replace.
Malfunction of accelerator pedal position
sensor
Inspect referring to “DTC P0122: Throttle
Position Sensor (Main) Circuit Low: in Section
1A”, “DTC P0123: Throttle Position Sensor
(Main) Circuit High: in Section 1A”, “DTC
P0222: Throttle Position Sensor (Sub) Circuit
Low: in Section 1A” and “DTC P0223: Throttle
Position Sensor (Sub) Circuit High: in Section
1A”.
Faulty valve body component Replace valve body assembly.
Condition Possible cause Correction / Reference Item
