Suzuki LT-A400F Service Manual

Front Suspension: 2B-12
Specifications
Tightening Torque Specifications
B827H12207001
NOTE
The specified tightening torque is also described in the following.
“Front Suspension Components (Page 2B-1)”
“Front Suspension Assembly Construction (Page 2B-2)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List (LT-A400/F) in
Section 0C (Page 0C-9)”.
Special Tools and Equipment
Recommended Service Material
B827H12208001
NOTE
Required service material is also described in the following.
“Front Suspension Components (Page 2B-1)”
“Front Suspension Assembly Construction (Page 2B-2)”
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Front shock absorber mounting bolt (upper) 55 5.5 40.0 )(Page 2B-3)
Front shock absorber mounting bolt (lower) 60 6.0 43.5 )(Page 2B-3)
Steering knuckle pinch bolt 50 5.0 36.0 )(Page 2B-4)
Tie-rod end nut 29 2.9 21.0 )(Page 2B-5)
Brake disc cover mounting bolt 12 1.2 8.5 )(Page 2B-5)
Front hub nut 110 11.0 79.5 )(Page 2B-6)
Suspension arm pivot nut (upper) 65 6.5 47.0 )(Page 2B-9)
Suspension arm pivot nut (lower) 65 6.5 47.0 )(Page 2B-9)
Front shock absorber mounting nut (lower) 60 6.0 43.5 )(Page 2B-9)
Material SUZUKI recommended product or Specification Note
Grease SUZUKI SUPER GREASE A or
equivalent
P/No.: 99000–25010 )(Page 2B-4) / )(Page 2B-
5) / )(Page 2B-7)
Thread lock cement THREAD LOCK CEMENT SUPER
1303 or equivalent
P/No.: 99000–32030 )(Page 2B-4) / )(Page 2B-
9) / )(Page 2B-9)
THREAD LOCK CEMENT SUPER
1360 or equivalent
P/No.: 99000–32130 )(Page 2B-5)
