Lighting Systems:
9B-3
Headlight Component
s
B827H19206002
Headlight Removal and Inst
allation
B827H19206003
Removal
1)
Disconnect the headlight coup
ler (1).
2)
Remove the headlight with the housing (2).
1
1
I827H192000
4-01
1.
Headlight bulb (1
2 V 35/35 W x2)
1
I827H19
20005-01
2
I827H19200
06-03
478
480
