Parking Brake: 4D-3
Parking / Rear Brake Cable Removal and
Installation
B827H14406002
Removal
1) Remove the seat and side cover. Refer to “Exterior
Parts Removal and Installation in Section 9D
(Page 9D-3)”.
2) Remove the parking/rear brake cable as shown in
the brake cable routing diagram. Refer to “Brake
Cable Routing Diagram in Section 4A (Page 4A-2)”.
Installation
1) Install the parking/rear brake cable as shown in the
brake cable routing diagram. Refer to “Brake Cable
Routing Diagram in Section 4A (Page 4A-2)”.
2) After installing the parking/rear brake cable, check
the parking (rear brake) lever play. Refer to “Rear
Brake Pedal / Rear Brake (Parking Brake) Lever
Inspection and Adjustment in Section 0B (Page 0B-
16)”.
3) Install the side cover and seat.
Specifications
Tightening Torque Specifications
B827H14407001
NOTE
The specified tightening torque is also described in the following.
“Parking / Rear Brake Lever Components (Page 4D-1)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List (LT-A400/F) in
Section 0C (Page 0C-9)”.
Special Tools and Equipment
Recommended Service Material
B827H14408001
NOTE
Required service material is also described in the following.
“Parking / Rear Brake Lever Components (Page 4D-1)”
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Brake lever pivot bolt 6 0.6 4.5 )(Page 4D-2)
Brake lever pivot bolt lock-nut 6 0.6 4.5 )(Page 4D-2)
Material SUZUKI recommended product or Specification Note
Grease SUZUKI SUPER GREASE A or
equivalent
P/No.: 99000–25010 )(Page 4D-2) / )(Page 4D-
2)
