Suzuki LT-A400F Service Manual

9E-7 Body Structure:
Specifications
Tightening Torque Specifications
B827H19507001
NOTE
The specified tightening torque is also described in the following.
“Body Frame Construction (Page 9E-1)”
“Footrest Construction (Page 9E-1)”
“Carrier Construction (Page 9E-3)”
“Front Grip Bar Construction (Page 9E-5)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List (LT-A400/F) in
Section 0C (Page 0C-9)”.
Special Tools and Equipment
Recommended Service Material
B827H19508001
NOTE
Required service material is also described in the following.
“Footrest Construction (Page 9E-1)”
“Carrier Construction (Page 9E-3)”
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Footrest mounting bolt (M10) 55 5.5 40.0 )(Page 9E-2)
Footrest mounting bolt (M8) 25 2.5 18.0 )(Page 9E-2)
Front carrier mounting bolt 28 2.8 20.0 )(Page 9E-4)
Rear carrier mounting bolt 28 2.8 20.0 )(Page 9E-4)
Front grip bar mounting bolt 28 2.8 20.0 )(Page 9E-6)
Rear axle housing mounting bolt (final gear
case)
55 5.5 40.0
)(Page 9E-6)
Material SUZUKI recommended product or Specification Note
Thread lock cement THREAD LOCK CEMENT SUPER
1303 or equivalent
P/No.: 99000–32030 )(Page 9E-6)
THREAD LOCK CEMENT SUPER
1322 or equivalent
P/No.: 99000–32110 )(Page 9E-2) / )(Page 9E-
4)
