0B-7 Maintenance and Lubrication:
Spark Arrester Cleaning
B827H10206006
Clean spark arrester
Every 2 000 km (1 200 miles, 6 months)
Clean the spark arrester in the following procedures:
1) Remove the spark arrester (1) from the muffler.
2) Clean the spark arrester with a brush.
WARNING
!
Only clean the spark arrester in an open area
away from combustible materials. Exhausted
hot carbon particles can start a fire.
3) Reinstall the spark arrester.
Fuel Line Inspection
B827H10206007
Inspect fuel line
Every 1 000 km (600 miles, 3 months)
Replace fuel line
Every 4 years
Inspect the fuel line in the following procedures:
1) Remove the left side cover. Refer to “Exterior Parts
Removal and Installation in Section 9D (Page 9D-
3)”.
2) Inspect the fuel hose (1) for damage and fuel
leakage. If any defects are found, the fuel feed hose
must be replaced.
3) After finishing the fuel feed hose inspection or
replacement, reinstall the removed parts.
Engine Oil and Filter Replacement
B827H10206008
Replace engine oil
Initially at 200 km (100 miles, 1 month) and every 2
000 km (1 200 miles, 6 months) thereafter
Replace oil filter
Initially at 200 km (100 miles, 1 month) and every 2
000 km (1 200 miles, 6 months) thereafter
Oil Level Inspection
1) Place the vehicle on a level ground and set the brake
lock.
2) Start up the engine and allow it to run for several
minutes at idling speed.
3) Turn off the engine and wait about three minutes,
then remove the oil filter cap (dipstick) (1).
1
I827H1020004-01
I827H1020037-01
[A] LT-A400/F [B] LT-F400/F
1
I827H1020005-02
1
1
[A]
[B]
I827H1020006-01
