9C-1
Co
mbination Mete
r
/ Fuel Meter / Horn:
Body and Acc
essories
Combination Meter / Fuel Meter / Horn
Rep
air Instructions
Speedometer Componen
t
s
B827H19306001
1
2
3
4
5
I827H193000
1-01
1.
S
peedometer
3.
S
peedometer light bulb (12V 1.7 W)
5.
Indicator light bulb (12V 3.4 W)
2.
Damper
4.
Speed
ometer bracket
483
485
