Suzuki LT-A400F Service Manual

Service Data: 0C-11
Tightening Torque List (LT-F400/F)
B827H10307004
Engine
Brake disc bolt 23 2.3 16.5
Brake caliper mounting bolt 26 2.6 19.0
Footrest mounting bolt
M8 25 2.5 18.0
M10 55 5.5 40.0
Rear brake cam lever nut 11 1.1 8.0
Rear axle housing mounting bolt (Final gear case) 55 5.5 40.0
Rear axle housing mounting bolt (Swingarm) 60 6.0 43.5
Rear shock absorber mounting nut
Upper 35 3.5 25.5
Lower 60 6.0 43.5
Rear swingarm pivot nut 102 10.2 74.0
Brake disc cover mounting bolt 12 1.2 8.5
Brake pipe flare nut 16 1.6 11.5
Master cylinder holder bolt (Upper & lower) 10 1.0 7.0
Brake lever pivot bolt 6 0.6 4.5
Brake lever pivot bolt lock-nut 6 0.6 4.5
Rear brake pedal pivot nut 12 1.2 8.5
Front brake pad mounting pin 18 1.8 13.0
Front brake hose union bolt 23 2.3 16.5
Caliper holder slide pin nut 23 2.3 16.5
Caliper holder pin 18 1.8 13.0
Rear brake anchor panel nut 32 3.2 23.0
Steering shaft lower nut 49 4.9 35.5
Front carrier mounting bolt 28 2.8 20.0
Rear carrier mounting bolt 28 2.8 20.0
Front grip bar mounting bolt 28 2.8 20.0
Item N⋅m kgf-m lb-ft
Item N⋅m kgf-m lb-ft
Cylinder head cover bolt 10 1.0 7.0
Camshaft sprocket bolt 15 1.5 11.0
Cylinder head bolt
initial 25 2.5 18.0
Final 37 3.7 26.5
Cylinder head nut
initial 10 1.0 7.0
Final 25 2.5 18.0
Cylinder base nut 10 1.0 7.0
Cam chain tensioner bolt 13 1.3 9.5
Cam chain tension adjuster bolt 10 1.0 7.0
Cam chain tension adjuster spring holder bolt 8 0.8 6.0
Spark plug 11 1.1 8.0
Valve clearance adjuster lock-nut 10 1.0 7.0
Rocker arm shaft bolt 28 2.8 20.0
Crankcase bolt
M6 11 1.1 8.0
M8 26 2.6 19.0
TDC plug 23 2.3 16.5
Clutch shoe nut 145 14.5 105.0
Clutch sleeve hub nut 100 10.0 72.5
Generator rotor nut 140 14.0 101.0
Starter clutch bolt 26 2.6 19.0
Starter cup nut 38 3.8 27.5
Clutch release adjusting screw lock-nut (1) 10 1.0 7.0
Clutch release adjusting screw lock-nut (2) 23 2.3 16.5
Oil pump drive gear bolt 80 8.0 58.0
Oil pressure regulator 23 2.3 16.5
Cooling fan thermo-switch 20 2.0 14.5
Engine oil temperature switch 23 2.3 16.5
Exhaust pipe nut 18 1.8 13.0
Exhaust pipe mounting bolt 23 2.3 16.5
