9A-10 Wiring Systems:
Specifications
Service Data (LT-A400/F, LT-F400/F)
B827H19107001
Electrical
Unit: mm
Tightening Torque Specifications
B827H19107002
NOTE
The specified tightening torque is also described in the following.
“Wiring Harness Routing Diagram (Page 9A-8)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List (LT-A400/F) in
Section 0C (Page 0C-9)”.
4. Magneto lead wire “b”: 45°
“A”: When tightening the starter motor mounting bolts, tighten the rear one first. “c”: Within 45°
: 10 N⋅m (1.0 kgf-m, 7.0 lb-ft)
Item Specification Note
Fuse size
Headlight
HI 10 A
LO 10 A
Brake light 10 A
Ignition 10 A
Power source 10 A
Fan 10 A
Main 30 A
