Display group Button
Higher Press ↑ button
Lower Press ↓ button
Skip Press ← button.
If the specifications are attained in all display zones:
– Exit diagnosis function.
– Switch off ignition.
5.3 Evaluating measured value blocks at
idling speed
Always follow safety precautions ⇒ Page 93.
Read measured value block ⇒ Page 94.
Display group:
◆ 1 - Injected quantity ⇒ Page 95,
◆ 2 - Idling speed ⇒ Page 96,
◆ 3 - Exhaust gas recirculation ⇒ Page 97,
◆ 4 - Activation of injectors -N30...N33- ⇒ Page 97,
◆ 7 - Temperatures ⇒ Page 98,
◆ 10 - Air quantities ⇒ Page 98,
◆ 11 - Charge pressure control ⇒ Page 99,
◆ 12 - Status ⇒ Page 99,
◆ 13 - Smooth running control ⇒ Page 101,
◆ 20 - Fuel rail values 3 ⇒ Page 101,
◆ 30 - Pedal encoder ⇒ Page 102,
◆ 34 - Charge pressure positioner ⇒ Page 103,
◆ 99 - Exhaust gas temperature sender ⇒ Page 103,
◆ 100 - Diesel particulate filter, exhaust gas temperature, dif-
ferential pressure ⇒ Page 104,
◆ 106 - Diesel particulate filter regeneration 6 ⇒ Page 105,
◆ 108 - Diesel particulate filter regeneration 8 ⇒ Page 105
5.3.1 Display group 1 - Injected quantity
Test prerequisites
● Engine running at idling speed.
● Engine warm, coolant temperature not below 80°C.
● Intake air temperature < 40°C.
Industriemotoren - Industrial Engines 2009 ▶
Workshop Manual for Diesel Engine (2.0 l/36-75 kW_EA 189) 05.2015
3
5 Measured value blocks, engine codes CJDA, CJDD
95
