Sealing flange at belt pulley end - Prescribed torque and
tightening sequence
– Tighten bolts in 3 stages in the sequence shown:
Stage Bolts Specified torque
1. -1 … 10- Screw in to contact by hand
2. -1 … 6- Diagonally in stages; final torque
15 Nm
3. -7 … 10- 15 Nm
2.2 Renewing crankshaft oil seal - pulley
end
Note
â—† The repair work described in this chapter must be carried out
in a Volkswagen dealership only. Go to a Volkswagen deal-
ership.
â—† If these instructions are not adhered to and damage results,
Volkswagen is exempt from any liability and warranty claims.
WARNING
Adhere to the general safety regulations and the notes on
repair work on the engine! ⇒ Page 1
Industriemotoren - Industrial Engines 2009 ▶
Workshop Manual for Diesel Engine (2.0 l/36-75 kW_EA 189) 05.2015
3
2 Removing and installing sealing flange and flywheel
161
