11 - Ancillary bracket
q For alternator, air conditioner compressor, if fitted
q Removing and installing, adhere to tightening sequence ⇒ Page 144
12 - Bolt
q Observe different prescribed torques and tightening sequence ⇒ Page 144
13 - 25 Nm
14 - Sump
q Clean sealing surface before fitting.
q Install with silicone sealant D176404 A2
q Removing and installing ⇒ Page 244
15 - 15 Nm
2 Removing and installing sealing
flange and flywheel
Note
â—† The repair work described in this chapter must be carried out
in a Volkswagen dealership only. Go to a Volkswagen deal-
ership.
â—† If these instructions are not adhered to and damage results,
Volkswagen is exempt from any liability and warranty claims.
WARNING
Adhere to the general safety regulations and the notes on
repair work on the engine! ⇒ Page 1
Note
Before carrying out repair work, secure engine on engine and
gearbox support -VAS 6095/1- using universal mounting
-VAS 6095-.
Assembly overview - sealing flange, belt pulley end
⇒ Page 159.
Renewing crankshaft oil seal, belt pulley end ⇒ Page 161.
Removing and installing crankshaft sealing flange, pulley end
⇒ Page 164.
Assembly overview - sealing flange and flywheel ⇒ Page 167.
Renewing crankshaft sealing flange, flywheel end ⇒ Page 169.
Removing and installing engine speed sender -G28-
⇒ Page 178.
3
Industriemotoren - Industrial Engines 2009 ▶
Workshop Manual for Diesel Engine (2.0 l/36-75 kW_EA 189) 05.2015
158
Repair Group 13 - Crankshaft group
