– Loosen sump with light blows of a rubber headed hammer if
necessary.
– Remove sealant residue from cylinder block with a flat scra-
per.
WARNING
Wear eye protection.
– Remove sealant residue on sump with a rotating brush, e.g.
a hand drill with a plastic brush.
– Clean sealing surfaces. They must be free of oil and grease.
2.2.2 Installing
Note
â—† Note the expiry date of the sealant.
â—† Install sump within 5 minutes of applying silicone sealant.
– Cut off tube nozzle at front marking (nozzle diameter approx.
3 mm).
– Apply silicone sealant, as shown, to clean sump sealing sur-
face. Sealant bead must be:
◆ 2…3 mm thick.
â—† Run bead along inner side of bolt holes -arrows-.
Note
The sealant bead must not be thicker, otherwise excess sealant
may enter the oil sump and block the oil suction line strainer.
Industriemotoren - Industrial Engines 2009 ▶
Workshop Manual for Diesel Engine (2.0 l/36-75 kW_EA 189) 05.2015
3
2 Parts of lubrication system
259
