6.3.26 Display group 250
Display
zone
Operating mode or component Value range Evaluation
1 Working speed control switch, specified
engine speed
0 .. 5865 rpm ---
2 Specified engine speed via buttons 0 .. 5865 rpm ---
3 CAN, specified engine speed 0 .. 5865 rpm ---
4 Accelerator pedal, specified engine speed 0 .. 5865 rpm ---
6.3.27 Display group 253
Display
zone
Operating mode or component Value range Evaluation
1 Radiator fan 1, activation -101 .. 100.2 % ---
2 Status: switch on alternator 00000000 .. 11111111 ---
3 Clutch status 00000000 .. 11111111 ---
4 Brake status 0 .. 255 ---
6.3.28 Display group 254
Display
zone
Operating mode or component Value range Evaluation
1 Engine speed 0 .. 5865 rpm ---
2 Status of regeneration and ash deposit
mass adaptation (only CPYA and CPYB)
0 .. 255 - CAN available = 1 in
doc. for commission-
ing (coding) -> request
message "Vehicle is se-
cured" -> 255 = mes-
sage not received (re-
generation does not
start)
3 --- --- ---
4 --- --- ---
6.4 Evaluating measured value blocks at
full load (engine code CPYA)
Note conditions for measurements at full load ⇒ Page 125.
Display group:
◆ 1 - Injected quantity ⇒ Page 126,
◆ 3 - Exhaust gas recirculation ⇒ Page 127,
◆ 8 - Torque limit 1 ⇒ Page 128,
◆ 11 - Charge pressure control ⇒ Page 128,
6.4.1 Conditions for measurements at full load
Always follow safety precautions ⇒ Page 110.
Industriemotoren - Industrial Engines 2009 ▶
Workshop Manual for Diesel Engine (2.0 l/36-75 kW_EA 189) 05.2015
3
6 Measured value blocks, engine codes CPYA, CPYB, CPYC, CPYD, CPYE, CPYF, CPYG
125
