100 Program features
 List of the tasks and the relevant drive parameters
Depending on the selection made in the Application task (parameter 9902 APPLIC
MACRO), the Start-up assistant decides which consequent tasks it suggests.
Name Description Set parameters
Language select Selecting the language 9901
Motor set-up Setting the motor data 9905…9909
Application Selecting the application macro 9902, parameters
associated to the macro
Option modules Activating the option modules Group 35: Motor temp
meas, Group 52: Panel
comm, 9802
Speed control EXT1 Selecting the source for the speed (output
frequency) reference
1103
(If AI1 is used: Setting analog input AI1
limits, scale, inversion)
(1301…1303, 3001)
Setting the reference limits 1104, 1105
Setting the frequency limits 2007, 2008
Setting the acceleration and deceleration
times
2202, 2203
Speed control EXT2 Selecting the source for the speed (output
frequency) reference
1106
(If AI1 is used: Setting analog input AI1
limits, scale, inversion)
(1301…1303, 3001)
Setting the reference limits 1107, 1108
PID control Selecting the source for the process
reference
1106
(If AI1 is used: Setting analog input AI1
limits, scale, inversion)
(1301…1303, 3001)
Setting the reference limits 1107, 1108
Setting the speed (reference) limits 2007, 2008
Setting the source and limits for the
process actual value
4016, 4018, 4019
Start/Stop control Selecting the source for start and stop
signals of the two external control
locations, EXT1 and EXT2
1001, 1002
Selecting between EXT1 and EXT2 1002
Defining the direction control 1003
Defining the start and stop modes 2101…2103
Selecting the use of Run Enable signal 1601
Protections Setting the current limits 2003
Output signals Selecting the signals indicated through
relay output RO
Group 14: Relay outputs
Selecting the signals indicated through
analog output AO
Setting the minimum, maximum, scaling
and inversion
Group 15: Analogue
outputs

ABB ACS320 Specifications

General

Overload Capacity	150% for 60 seconds
IP Rating	IP20
Frame Size	R1 to R3
Enclosure Rating	IP20
Frequency Range	0 to 500 Hz
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Short circuit, Ground fault, Overtemperature
Fieldbus Communication	Modbus RTU, PROFIBUS DP, CANopen
Communication Interfaces	RS485
Operating Temperature	-10 to +50 °C (14 to 122 °F)
Storage Temperature	-40°C to +70°C
Humidity	Less than 95% (non-condensing)
Supply Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
