ABB ACS320 User Manual

Program features 111
Frequency input
Digital input DI5 can be programmed as a frequency input. Frequency input
(0…16000 Hz) can be used as external reference signal source. The update time for
the frequency input is 50 ms. Update time is shorter when information is transferred
to the application program (50 ms -> 2 ms).
 Settings
 Diagnostics
Transistor output
The drive has one programmable transistor output. The output can be used either as
digital output or frequency output (0…16000 Hz). The update time for the
transistor/frequency output is 2 ms.
 Settings
 Diagnostics
Parameter Additional information
Group 18: Freq in & tran out Frequency input minimum and maximum values and
filtering
1103/1106 External reference REF1/2 through frequency input
4010, 4110, 4210 Frequency input as PID reference source
Actual signal Additional information
0161 Frequency input value
Parameter Additional information
Group 18: Freq in & tran out Transistor output settings
Actual signal Additional information
0163 Transistor output status
0164 Transistor output frequency

ABB ACS320 Specifications

General

Overload Capacity	150% for 60 seconds
IP Rating	IP20
Frame Size	R1 to R3
Enclosure Rating	IP20
Frequency Range	0 to 500 Hz
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Short circuit, Ground fault, Overtemperature
Fieldbus Communication	Modbus RTU, PROFIBUS DP, CANopen
Communication Interfaces	RS485
Operating Temperature	-10 to +50 °C (14 to 122 °F)
Storage Temperature	-40°C to +70°C
Humidity	Less than 95% (non-condensing)
Supply Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
