ABB ACS320 User Manual

Operation principle and hardware description 27
Type designation key
The type designation contains information on the specifications and configuration of
the drive. You find the type designation on the type designation label attached to the
drive. The first digits from the left express the basic configuration, for example
ACS320-03U-09A7-4. The optional selections are given after that, separated by +
signs, for example +J404. The explanations of the type designation selections are
described below.
ACS320 product series
01 = 1-phase input
03 = 3-phase input
1-phase/3-phase
In format xxAy, where xx indicates the integer part and y the fractional part,
eg, 08A8 means 8.8 A. For more information on ratings, types and voltages, see
sections starting on page 383.
2 = 200 … 240 V AC
4 = 380 … 480 V AC
Input voltage range
E = EMC filter connected, 50 Hz frequency
U = EMC filter disconnected, 60 Hz frequency
1) The ACS320 is compatible with panels that have the following panel revisions and panel firmware
versions.
2) Available for North American market only.
Panel type Typ e c ode Panel revision Panel firmware version
Basic control panel
2)
ACS-CP-C M or later 1.13 or later
Advanced HVAC control panel ACH-CP-B X or later 2.04 or later
Options
ACS320-03X-08A8-4+J404+...
Output current rating
Configuration
J404 = ACS-CP-C basic control panel
1) 2)
J400 = ACH-CP-B advanced HVAC control panel
1)
R700 = ACS320 user’s manual in English (3AUA0000062599 [EN])
E202 = RFI filter (available for European market only)

ABB ACS320 Specifications

General

Overload Capacity	150% for 60 seconds
IP Rating	IP20
Frame Size	R1 to R3
Enclosure Rating	IP20
Frequency Range	0 to 500 Hz
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Short circuit, Ground fault, Overtemperature
Fieldbus Communication	Modbus RTU, PROFIBUS DP, CANopen
Communication Interfaces	RS485
Operating Temperature	-10 to +50 °C (14 to 122 °F)
Storage Temperature	-40°C to +70°C
Humidity	Less than 95% (non-condensing)
Supply Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
