Actual signals and parameters 185
 Group 17: Override
This group defines the source for the override activation signal, the override speed/
frequency and pass code and how the override is enabled and disabled.
When override DI is activated, the drive stops and then accelerates to the preset
speed or frequency. When the DI is deactivated the drive stops and reboots. If the
start command, run enable and start enables are active in the AUTO mode the drive
starts automatically and continues normally after override mode. In the HAND mode
the drive returns to OFF mode.
When override is active:
• Drive runs at preset speed.
• Drive ignores all keypad commands.
• Drive ignores all commands from communication links.
• Drive ignores all digital inputs except override activation/deactivation, RUN
ENABLE and START ENABLE.
• Drive displays alarm message 2020 OVERRIDE.
The following faults are ignored:
3 DEV OVERTEMP
5OVERLOAD
6 DC UNDERVOLT
7 AI1 LOSS
8 AI2 LOSS
9MOT OVERTEMP
10 PANEL LOSS
12 MOTOR STALL
14 EXT FAULT 1
15 EXT FAULT 2
17 UNDERLOAD
18 THERM FAIL
21 CURR MEAS
22 SUPPLY PHASE
24 OVERSPEED
28 SERIAL 1 ERR
29 EFB CON FILE
30 FORCE TRIP
31 EFB 1

ABB ACS320 Specifications

General

Overload Capacity	150% for 60 seconds
IP Rating	IP20
Frame Size	R1 to R3
Enclosure Rating	IP20
Frequency Range	0 to 500 Hz
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Short circuit, Ground fault, Overtemperature
Fieldbus Communication	Modbus RTU, PROFIBUS DP, CANopen
Communication Interfaces	RS485
Operating Temperature	-10 to +50 °C (14 to 122 °F)
Storage Temperature	-40°C to +70°C
Humidity	Less than 95% (non-condensing)
Supply Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
