ABB ACS320 User Manual

130 Program features
Timed functions
A variety of drive functions can be time controlled, eg start/stop and EXT1/EXT2
control. The drive offers
• four start and stop times (START TIME 1…4, STOP TIME 1…4)
• four start and stop days (START DAY 1…4, STOP DAY 1…4)
• four timed functions for collecting the selected time periods 1…4 together (TIMED
FUNC 1…4)
• booster time (an additional booster time connected to timed functions).
A timed function can be connected to multiple time periods:
Time period 1
3602 START TIME 1
3603 STOP TIME 1
3604 START DAY 1
Time period 4
3614 START TIME 4
3615 STOP TIME 4
3616 START DAY 4
3617 STOP DAY 4
Time period 3
3610 START TIME 3
3611 STOP TIME 3
3612 START DAY 3
3613 STOP DAY 3
Time period 2
3606 START TIME 2
3607 STOP TIME 2
3608 START DAY 2
3609 STOP DAY 2
Booster
3622 BOOSTER SEL
3623 BOOSTER TIME
Timed function 1
3626 TIMED FUNC 1 SRC
Timed function 2
3627 TIMED FUNC 2 SRC
Timed function 3
3628 TIMED FUNC 3 SRC
Timed function 4
3629 TIMED FUNC 4 SRC

ABB ACS320 Specifications

General

Overload Capacity	150% for 60 seconds
IP Rating	IP20
Frame Size	R1 to R3
Enclosure Rating	IP20
Frequency Range	0 to 500 Hz
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Short circuit, Ground fault, Overtemperature
Fieldbus Communication	Modbus RTU, PROFIBUS DP, CANopen
Communication Interfaces	RS485
Operating Temperature	-10 to +50 °C (14 to 122 °F)
Storage Temperature	-40°C to +70°C
Humidity	Less than 95% (non-condensing)
Supply Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
