Technical data 395
Electric power network specification
Voltage (U
1
) 200/208/220/230/240 V AC 1-phase for 200 V AC drives
200/208/220/230/240 V AC 3-phase for 200 V AC drives
380/400/415/440/460/480 V AC 3-phase for 400 V AC drives
±10% variation from converter nominal voltage is allowed as default.
Short-circuit capacity Maximum allowed prospective short-circuit current at the input power
connection as defined in IEC 60439-1 is 100 kA. The drive is suitable
for use in a circuit capable of delivering not more than 100 kA rms
symmetrical amperes at the drive maximum rated voltage.
Note: Use appropriate fuses or MMP’s to achieve 100 kA.
Frequency 50/60 Hz ± 5%, maximum rate of change 17%/s
Imbalance Max. ±3% of nominal phase to phase input voltage
Motor connection data
Voltage (U
2
) 0 to U
1
, 3-phase symmetrical, U
max
at the field weakening point
Short-circuit protection
(IEC 61800-5-1,
UL 508C)
The motor output is short-circuit proof by IEC 61800-5-1 and
UL 508C.
Frequency 0…500 Hz
Frequency resolution 0.01 Hz
Current See section Ratings on page 384 or Definitions on page 385.
Power limit 1.5 · P
N
Field weakening point 10…500 Hz
Switching frequency 4, 8, 12 or 16 kHz
Maximum
recommended
motor cable length
R0: 30 m (100 ft), R1…R4: 50 m (165 ft)
With output chokes the motor cable length may be extended to 60 m
(195 ft) for R0 and 100 m (330 ft) for R1…R4.
To comply with the European EMC Directive, use the cable lengths
specified in the table below for 4 kHz switching frequency. The
lengths are given for using the drive with the internal EMC filter or an
optional external EMC filter.
4 kHz switching
frequency
Internal EMC filter Optional external
EMC filter
Second environment
(category C3
1)
)
30 m (100 ft) 30 m (100 ft)
minimum
First environment
(category C2
1)
)
-30m (100ft)
1)
See the new terms in section Definitions on page 399.
