ABB ACS320 User Manual

328 Fieldbus control
*Object instance applies for US regional variant only.
Note: For Present Value Access Types, R = Read-only, W = Writeable,
C = Commandable. Commandable values support priority arrays & relinquish
defaults.
 Analog input object instance summary
The following table summarizes the Analog input objects supported:
Note: For Present Value Access Types, R = Read-only, W = Writeable,
C = Commandable. Commandable values support priority arrays & relinquish
defaults.
 Analog output object instance summary
The following table summarizes the Analog output objects supported:
Note: For Present Value Access Types, R = Read-only, W = Writeable,
C = Commandable. Commandable values support priority arrays & relinquish
defaults.
BV22* HEATING CMD Command to automatically
assert Motor Heating DC
current injection, when drive
is stopped (drive must be
configured for BACnet
control).
In this mode, “DISABLE”
turns off the ongoing Motor
Heating operation
immediately (after the drive
has received the command).
ENABLE/DISABLE C
BV23* HEATING STS Indicates the status of Motor
Heating DC current injection
(drive must be configured
for BACnet control).
“ON” means there is actual
heating current flowing in
the motor circuit.
ON/OFF R
Instance
ID
Object Name Description Units
Present Value
Access Type
AI0 ANALOG INPUT
1
Indicates the input level of Analog
Input 1.
Percent R
AI1 ANALOG INPUT
2
Indicates the input level of Analog
Input 2.
Percent R
Instance
ID
Object Name Description Units
Present Value
Access Type
AO0 AO 1
COMMAND
Controls Analog Output 1 (drive must
be configured for BACnet control).
Percent C
Instance
ID
Object Name Description
Active/Inactive
Text
Present Value
Access Type

ABB ACS320 Specifications

General

Overload Capacity	150% for 60 seconds
IP Rating	IP20
Frame Size	R1 to R3
Enclosure Rating	IP20
Frequency Range	0 to 500 Hz
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Short circuit, Ground fault, Overtemperature
Fieldbus Communication	Modbus RTU, PROFIBUS DP, CANopen
Communication Interfaces	RS485
Operating Temperature	-10 to +50 °C (14 to 122 °F)
Storage Temperature	-40°C to +70°C
Humidity	Less than 95% (non-condensing)
Supply Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
