Drive manuals Code (English)

ACS320 drives (0.5 to 30 hp) user’s manual 3AUA0000062599

ACS320 Short Form User’s Manual 3AUA0000086933

Option manuals and guides

MFDT-01 FlashDrop user’s manual 3AFE68591074

MREL-01 output relay module user’s manual 3AUA0000035974

MUL1-R1 installation instructions for ACS150, ACS310,

ACS320, ACS350 and ACS355

3AFE68642868

MUL1-R3 installation instructions for ACS310, ACS320,

ACS350 and ACS355

3AFE68643147

MUL1-R4 installation instructions for ACS310, ACS320,

ACS350 and ACS355

3AUA0000025916

SREA-01 Ethernet adapter module quick start-up guide 3AUA0000042902

SREA-01 Ethernet adapter module user’s manual 3AUA0000042896

Maintenance manuals

Guide for capacitor reforming in ACS50, ACS55,

ACS150, ACS310, ACS350, ACS355, ACS550,

ACH550 and R1-R4 OINT-/SINT-boards

3AFE68735190

Other manuals for ABB ACS320

Questions and Answers:

Need help?

Do you have a question about the ABB ACS320 and is the answer not in the manual?

General

Overload Capacity	150% for 60 seconds
IP Rating	IP20
Frame Size	R1 to R3
Enclosure Rating	IP20
Frequency Range	0 to 500 Hz
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Short circuit, Ground fault, Overtemperature
Fieldbus Communication	Modbus RTU, PROFIBUS DP, CANopen
Communication Interfaces	RS485
Operating Temperature	-10 to +50 °C (14 to 122 °F)
Storage Temperature	-40°C to +70°C
Humidity	Less than 95% (non-condensing)
Supply Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
