392 Technical data
Dimensions, weights and free space requirements
 Dimensions and weights
 Free space requirements
Frame
size
Dimensions and weights
IP20 (cabinet) / UL open
H1 H2 H3 W D Weight
mm in mm in mm in mm in mm in kg lb
R0 169 6.65 202 7.95 239 9.41 70 2.76 161 6.34 1.2 2.6
R1 169 6.65 202 7.95 239 9.41 70 2.76 161 6.34 1.4 3.1
R2 169 6.65 202 7.95 239 9.41 105 4.13 165 6.50 1.8 4.0
R3 169 6.65 202 7.95 236 9.29 169 6.65 169 6.65 2.9 6.4
R4 181 7.13 202 7.95 244 9.61 260 10.24 169 6.65 5.1 11.2
00578903.xls G
Frame
size
Dimensions and weights
IP20 / NEMA 1
H4 H5 W D Weight
mm in mm in mm in mm in kg lb
R0 257 10.12 280 11.02 70 2.76 169 6.65 1.6 3.5
R1 257 10.12 280 11.02 70 2.76 169 6.65 1.8 4.0
R2 257 10.12 282 11.10 105 4.13 169 6.65 2.2 4.9
R3 260 10.24 299 11.77 169 6.65 177 6.97 3.5 7.7
R4 270 10.63 320 12.60 260 10.24 177 6.97 5.7 12.6
00578903.xls G
Symbols
IP20 (cabinet) / UL open
H1 height without fastenings and clamping plate
H2 height with fastenings, without clamping plate
H3 height with fastenings and clamping plate
IP20 / NEMA 1
H4 height with fastenings and connection box
H5 height with fastenings, connection box and hood
Frame
size
Free space required
Above Below On the sides
mm in mm in mm in
R0…R4753753 0 0

ABB ACS320 Specifications

General

Overload Capacity	150% for 60 seconds
IP Rating	IP20
Frame Size	R1 to R3
Enclosure Rating	IP20
Frequency Range	0 to 500 Hz
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Short circuit, Ground fault, Overtemperature
Fieldbus Communication	Modbus RTU, PROFIBUS DP, CANopen
Communication Interfaces	RS485
Operating Temperature	-10 to +50 °C (14 to 122 °F)
Storage Temperature	-40°C to +70°C
Humidity	Less than 95% (non-condensing)
Supply Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
