160 Actual signals and parameters
Group 10: Start/Stop/Dir
This group:
Defines external sources (EXT1, and EXT2) for commands that enable start, stop
and direction changes.
Locks direction or enables direction control. To select between the two external
locations use the next group, parameter 1102 EXT1/EXT2 SEL.
Group 10: Start/Stop/Dir
Code Description Range Resolution Default S
1001
EXT1 COMMANDS
0...34 1 1
Defines external control location 1 (EXT1) the configuration of start, stop and
direction commands.
0 = NOT SEL – No external start, stop and direction command source.
1 = DI1 – Two-wire Start/Stop.
Start/Stop is through digital input DI1 (DI1 activated = Start; DI1 de-activated =
Stop).
Parameter 1003 DIRECTION defines the direction. Selecting 1003 = 3 (request)
is the same as 1003 = 1 (fwd).
2 = DI1, 2 – Two-wire Start/Stop, Direction.
Start/Stop is through digital input DI1 (DI1 activated = Start; DI1 de-activated =
Stop).
Direction control (requires parameter 1003 = 3 (request)) is through digital input
DI2 (DI2 activated = Reverse; de-activated = Forward).
3 = DI1P, 2P – Three-wire Start/Stop.
Start/Stop commands are through momentary push-buttons (the P stands for
“pulse”).
Start is through a normally open push-button connected to digital input 1. In order
to start the drive, the digital input 2 must be activated prior the pulse in 1.
Connect multiple Start push-buttons in parallel.
Stop is through a normally closed push-button connected to digital input 2.
Connect multiple Stop push-buttons in series.
Parameter 1003 DIRECTION defines the direction. Selecting 1003 = 3
(REQUEST) is the same as 1003 = 1 (FWD).
4 = DI1P, 2P, 3 – Three-wire Start/Stop, Direction.
Start/Stop commands are through momentary push-buttons, as described for
DI1P, 2P.
Direction control (requires parameter 1003 = 3 (REQUEST)) is through digital
input DI3 (DI3 activated = Reverse; de-activated = Forward).
