Fieldbus control 325
BACnet protocol technical data
 Binary input object instance summary
The following table summarizes the Binary input objects supported:
Note: For Present Value Access Types, R = Read-only, W = Writeable, C =
Commandable. Commandable values support priority arrays & relinquish defaults.
 Binary output object instance summary
The following table summarizes the Binary output objects supported:
Note: For Present Value Access Types, R = Read-only, W = Writeable, C =
Commandable. Commandable values support priority arrays & relinquish defaults.
Instance
ID
Object
Name
Description
Active/
Inactive Text
Present Value
Access Type
BI0 RO 1 ACT Indicates status of Relay Output 1. ON/OFF R
BI1 RO 2 ACT Indicates status of Relay Output 2
(requires OREL-xx option).
ON/OFF R
BI2 RO 3 ACT Indicates status of Relay Output 3
(requires OREL-xx option).
ON/OFF R
BI3 RO 4 ACT Indicates status of Relay Output 4
(requires OREL-xx option).
ON/OFF R
BI6 DI 1 ACT Indicates status of Digital Input 1. ON/OFF R
BI7 DI 2 ACT Indicates status of Digital Input 2. ON/OFF R
BI8 DI 3 ACT Indicates status of Digital Input 3. ON/OFF R
BI9 DI 4 ACT Indicates status of Digital Input 4. ON/OFF R
BI10 DI 5 ACT Indicates status of Digital Input 5. ON/OFF R
BI12 TO ACT Indicates status of Transistor Output. ON/OFF R
Instance
ID
Object
Name
Description
Active/Inactive
Text
Present Value
Access Type
BO0 RO1 CMD Controls output state of Relay 1. ON/OFF C
BO1 RO2 CMD Controls output state of Relay 2.
(requires OREL-xx option).
ON/OFF C
BO2 RO3 CMD Controls output state of Relay 3.
(requires OREL-xx option).
ON/OFF C
BO3 RO4 CMD Controls output state of Relay 4.
(requires OREL-xx option).
ON/OFF C
BO6 TO CMD Controls output state of Transistor ON/OFF C

ABB ACS320 Specifications

General

Overload Capacity	150% for 60 seconds
IP Rating	IP20
Frame Size	R1 to R3
Enclosure Rating	IP20
Frequency Range	0 to 500 Hz
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Short circuit, Ground fault, Overtemperature
Fieldbus Communication	Modbus RTU, PROFIBUS DP, CANopen
Communication Interfaces	RS485
Operating Temperature	-10 to +50 °C (14 to 122 °F)
Storage Temperature	-40°C to +70°C
Humidity	Less than 95% (non-condensing)
Supply Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
