Installation checklist
Contents of this chapter
This chapter contains the task list to be followed after the mechanical and electrical
installation before proceeding to starting up the drive.
Checking the installation
Check the mechanical and electrical installation of the drive before start-up. Go
through the checklist below together with another person. Read chapter Safety on
page 15 of this manual before you work on the drive.
Check
MECHANICAL INSTALLATION
The ambient operating conditions are allowed. (See Mechanical installation: Checking the
installation site on page 29 as well as Technical data: Losses, cooling data and noise on
page 393 and Ambient conditions on page 397.)
The drive is fixed properly on an even vertical non-flammable wall. (See Mechanical
installation on page 29.)
The cooling air will flow freely. (See Mechanical installation: Free space around the drive
on page 30.)
The motor and the driven equipment are ready for start. (See Planning the electrical
installation: Checking the compatibility of the motor and drive on page 36 as well as
Technical data: Motor connection data on page 395.)
ELECTRICAL INSTALLATION (See Planning the electrical installation on page 35 and
Electrical installation on page 45.)
For ungrounded and corner grounded systems: The internal EMC filter is disconnected
(EMC screw removed).
The capacitors are reformed if the drive has been stored over a year.
The drive is grounded properly.
The input power voltage matches the drive nominal input voltage.
