112 Program features
Actual signals
Several actual signals are available:
• Drive output frequency, current, voltage and power
• Motor speed and torque
• Intermediate circuit DC voltage
• Active control location (LOCAL, EXT1 or EXT2)
• Reference values
• Drive temperature
• Operating time counter (h), kWh counter
• Digital I/O and analog I/O status
• PID controller actual values.
Three signals can be shown simultaneously on the assistant control panel display
(one signal on the basic panel display). It is also possible to read the values through
the serial communication link or through the analog outputs.
 Settings
 Diagnostics
Parameter Additional information
1501 Selection of an actual signal to AO
1801 Selection of an actual signal to frequency output
Group 32: Supervision Actual signal supervision
Group 34: Panel display Selection of an actual signals to be displayed on the
control panel
Actual signal Additional information
Group 01: Operating data … Group
04: Fault history
Lists of actual signals

ABB ACS320 Specifications

General

Overload Capacity	150% for 60 seconds
IP Rating	IP20
Frame Size	R1 to R3
Enclosure Rating	IP20
Frequency Range	0 to 500 Hz
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Short circuit, Ground fault, Overtemperature
Fieldbus Communication	Modbus RTU, PROFIBUS DP, CANopen
Communication Interfaces	RS485
Operating Temperature	-10 to +50 °C (14 to 122 °F)
Storage Temperature	-40°C to +70°C
Humidity	Less than 95% (non-condensing)
Supply Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
