Program features 131
A parameter which is triggered by a timed function can be connected to only one
timed function at a time.
 Examples
Air conditioning is active on weekdays from 8:00 to 15:30 (8 a.m to 3:30 p.m) and on
Sundays from 12:00 to 15:00 (12 to 3 p.m). By pressing the extension time switch,
the air-conditioning is on for an extra hour.
 Settings
Parameter Setting
3601 TIMERS ENABLE DI1
3602 START TIME 1 08:00:00
3603 STOP TIME 1 15:30:00
3604 START DAY 1 MONDAY
3605 STOP DAY 1 FRIDAY
3606 START TIME 2 12:00:00
3607 STOP TIME 2 15:00:00
3608 START DAY 2 SUNDAY
3609 STOP DAY 2 SUNDAY
3623 BOOSTER TIME 01:00:00
Parameter Additional information
Group 36: Timed functions Timed functions settings
1001, 1002 Timed start/stop control
1102 Timed EXT1/EXT2 selection
1201 Timed constant speed 1 activation
1209 Timed speed selection
1401 Timed function status indicated through relay output RO 1
1402/1403/1410 Timed function status indicated through relay output RO 2…4.
With option MREL-01 only.
Timed func 1
3626 TIMED FUNC 1 SRC
Timed func 2
3627 TIMED FUNC 2 SRC
1001 EXT 1 COMMANDS
1002 EXT 2 COMMANDS
11021201 CONST SPEED SEL
1209 TIME MODE SEL
1401 RELAY OUTPUT 1
4027 PID PARAM SET
4228 ACTIVATE

ABB ACS320 Specifications

General

Overload Capacity	150% for 60 seconds
IP Rating	IP20
Frame Size	R1 to R3
Enclosure Rating	IP20
Frequency Range	0 to 500 Hz
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Short circuit, Ground fault, Overtemperature
Fieldbus Communication	Modbus RTU, PROFIBUS DP, CANopen
Communication Interfaces	RS485
Operating Temperature	-10 to +50 °C (14 to 122 °F)
Storage Temperature	-40°C to +70°C
Humidity	Less than 95% (non-condensing)
Supply Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
