ABB ACS320 User Manual

384 Technical data
Ratings
Note: When choke is not used, input current is effected by supply network and
impedance.
Use the table in Fuses and alternate short-circuit protection (page 388) to correctly
size the input cabling as well as input fuses or MMP for branch circuit protection.
Sizing will be determined by the actual input current which is dependent on the input
line voltage and the input choke selection and rated motor current. If motor rated
current is below I
2N
, I
1N
is reduced relatively.
Type code Input Output Frame
size
without choke
or reactor
with choke or
5% reactor
ACS320- I
1N
I
1N
(480 V)
I
1N
I
1N
(480 V)
I
LD
2)
I
2N
I
2max
3)
P
N
x = E/U
1)
A A A A A A A kW hp
1-phase supply voltage 200…240 V units (Confirm output ratings meet motor requirements)
01x-02A4-2 6.1 - 4.5 - 2.3 2.4 4.0 0.37 0.5 R0
01x-04A7-2 11.4 - 8.1 - 4.5 4.7 7.9 0.75 1 R1
01x-06A7-2 16.1 - 11.0 - 6.5 6.7 11.4 1.1 1.5 R1
01x-07A5-2 16.8 - 12.0 - 7.2 7.5 12.6 1.5 2 R2
01x-09A8-2 21.0 - 15.0 - 9.4 9.8 16.5 2.2 3 R2
3-phase supply voltage 200…240 V units
03x-02A6-2 4.7 - 2.6 - 2.4 2.6 4.2 0.37 0.5 R0
03x-03A9-2 6.7 - 3.9 - 3.5 3.9 6.1 0.55 0.75 R0
03x-05A2-2 8.4 - 5.2 - 4.7 5.2 8.2 0.75 1 R1
03x-07A4-2 13.0 - 7.4 - 6.7 7.4 11.7 1.1 1.5 R1
03x-08A3-2 13.2 - 8.3 - 7.5 8.3 13.1 1.5 2 R1
03x-10A8-2 15.7 - 10.8 - 9.8 10.8 17.2 2.2 3 R2
03x-14A6-2 23.9 - 14.6 - 13.3 14.6 23.3 3 3 R2
03x-19A4-2 27.3 - 19.4 - 17.6 19.4 30.8 4 5 R2
03x-26A8-2 45.0 - 26.8 - 24.4 26.8 42.7 5.5 7.5 R3
03x-34A1-2 55.0 - 34.1 - 31.0 34.1 54.3 7.5 10 R4
03x-50A8-2 76.0 - 50.8 - 46.2 50.8 80.9 11.0 15 R4
3-phase supply voltage 380…480 V units
03x-01A2-4 2.4 2.0 1.3 1.1 1.1 1.2 2.1 0.37 0.5 R0
03x-01A9-4 4.0 3.3 2.0 1.7 1.7 1.9 3.3 0.55 0.75 R0
03x-02A4-4 4.5 3.8 2.5 2.1 2.2 2.4 4.2 0.75 1.0 R1
03x-03A3-4 6.6 5.5 3.5 2.9 3.0 3.3 5.8 1.1 1.5 R1
03x-04A1-4 7.6 6.3 3.8 3.2 3.7 4.1 7.2 1.5 2.0 R1
03x-05A6-4 10.6 8.8 5.3 4.4 5.1 5.6 9.8 2.2 3.0 R1
03x-07A3-4 12.8 10.7 6.8 5.7 6.6 7.3 12.8 3.0 3.0 R1
03x-08A8-4 15.0 12.5 8.6 7.2 8.0 8.8 15.4 4.0 5.0 R1
03x-12A5-4 20.7 17.2 12.3 10.3 11.4 12.5 21.9 5.5 7.5 R3

ABB ACS320 Specifications

General

Overload Capacity	150% for 60 seconds
IP Rating	IP20
Frame Size	R1 to R3
Enclosure Rating	IP20
Frequency Range	0 to 500 Hz
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Short circuit, Ground fault, Overtemperature
Fieldbus Communication	Modbus RTU, PROFIBUS DP, CANopen
Communication Interfaces	RS485
Operating Temperature	-10 to +50 °C (14 to 122 °F)
Storage Temperature	-40°C to +70°C
Humidity	Less than 95% (non-condensing)
Supply Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
