Customizable routing widgets Router Dynamic
FortiGate Version 4.0 MR1 Administration Guide
378 01-410-89802-20090903
http://docs.fortinet.com/ • Feedback
For more information on access list, see the “router” chapter of the FortiGate CLI
Reference.
Distribute List
The distribute list is a subcommand of OSPF. It filters the networks in routing updates
using an access or prefix list. Routes not matched by any of the distribution lists will not be
advertised. The offset list is part of the RIP and OSPF routing protocols. For more
information about OSPF, see “OSPF” on page 362.
Figure 199: Distribute List GUI widget
For more information on the distribute list, see the “router” chapter of the FortiGate CLI
Reference.
Key Chain
A key chain is a list of one or more keys and the send and receive lifetimes for each key.
Keys are used for authenticating routing packets only during the specified lifetimes. The
FortiGate unit migrates from one key to the next according to the scheduled send and
receive lifetimes. The sending and receiving routers should have their system dates and
times synchronized, but overlapping the key lifetimes ensures that a key is always
available even if there is some difference in the system times.
RIP version 2 uses authentication keys to ensure that the routing information exchanged
between routers is reliable. For authentication to work both the sending and receiving
routers must be set to use authentication, and must be configured with the same keys.
The offset list is part of the RIP and OSPF routing protocols. For more information about
RIP, see “RIP” on page 357.
Delete Icon Select delete to remove this access-list.
Add Icon Select to add a rule to this access-list. Rules include actions and prefixes.
Rules are processed from smallest to highest number.
Note: You must configure the access list that you want the distribution list to use before you
configure the distribution list. To configure an access list, see “Access List” on page 377.
Create New Select to create a new distribute list. This includes setting the direction,
selecting either the prefix-list or access-list, and interface.
Direction The name of the access list.
Filter The prefix-list or access-list to apply to this interface.
Interface The interface to apply the filter on.
Enable A green check indicates this distribute list is enabled.
Delete Icon Select to remove a distribution list rule.
Edit Icon Select to change the direction, filter, or interface of the distribute list.
