Fortinet FortiGate Series Administration Guide

Data Leak Prevention DLP Sensors
FortiGate Version 4.0 MR1 Administration Guide
01-410-89802-20090903 583
http://docs.fortinet.com/ • Feedback
Data Leak Prevention
You can use the FortiGate Data Leak Prevention (DLP) system to prevent sensitive data
from leaving or entering your network. You can define sensitive data patterns, and data
matching these patterns will be blocked and/or logged or archived when passing through
the FortiGate unit. The DLP system is configured by creating individual rules, combining
the rules into DLP sensors, and then assigning a sensor to a protection profile.
Although the primary use of the DLP feature is to stop sensitive data from leaving your
network, it can also be used to prevent unwanted data from entering your network and to
archive some or all of the content passing through the FortiGate unit.
This section provides an introduction to configuring DLP. For more information see the
FortiGate UTM User Guide.
If you enable virtual domains (VDOMs) on the Fortinet unit, data leak prevention is
configured separately for each virtual domain. For details, see “Using virtual domains” on
page 159.
The section describes:
• DLP Sensors
• DLP archiving
• DLP Rules
• DLP Compound Rules
DLP Sensors
DLP sensors are simply collections of DLP rules and DLP compound rules. The DLP
sensor also includes settings such as action, archive, and severity for each rule or
compound rule. Once a DLP sensor is configured, it can be specified in a protection
profile. Any traffic handled by the policy in which the protection profile is specified will
enforce the DLP sensor configuration.
Viewing the DLP sensor list
To view the available DLP sensors, go to UTM > Data Leak Prevention > Sensor.
Figure 357: DLP sensor list
Delete
Edit
