User Monitor
FortiGate Version 4.0 MR1 Administration Guide
01-410-89802-20090903 677
http://docs.fortinet.com/ • Feedback
Figure 422: Firewall user monitor list
IM user monitor list
User lists can be managed to allow or block certain users. Each user can be assigned a
policy to allow or block activity for each IM protocol. Each IM function can be individually
allowed or blocked providing the administrator the granularity to block the more bandwidth
consuming features such as voice chat while still allowing text messaging. The IM user
monitor list displays information about instant messaging users who are currently
connected. The list can be filtered by protocol. After IM users connect through the firewall,
the FortiGate unit displays which users are connected. You can analyze the list and
decide which users to allow or block.
To view the list of active IM users, go to User > Monitor > IM.
Refresh Refresh the Firewall user monitor list.
Current Page The current page number of list items that are displayed. Select the left and
right arrows to display the first, previous, next or last page of logged in users.
Column Settings Customize the table view. You can select the columns to hide or display and
specify the column displaying order in the table. For more information, see
“Using column settings to control the columns displayed” on page 103 and
“Web-based manager icons” on page 105.
Clear All Filters Remove all filters applied to the Firewall user monitor list.
De-authenticate All
Users
Stop authenticated sessions for all users in the Firewall user monitor list.
User(s) must re-authenticate with the firewall to resume their communication
session.
Filter icons Edit the column filters to filter or sort the firewall user monitor list according to
the criteria you specify. For more information, see “Adding filters to web-based
manager lists” on page 99.
User Name The user names of all connected remote users.
User Group The user group that the remote user is part of.
Duration Length of time since the user was authenticated.
Time-left Length of time remaining until the user session times out. Only available if the
authentication time of the session will be automatically extended
(authentication keepalive is enabled). If authentication keepalive is not
enabled, the value in Time-left will be N/A. For more information, see the
FortiGate CLI Reference.
IP Address The user’s source IP address.
Traffic Volume The amount of traffic through the FortiGate unit generated by the user.
Method Authentication method used for the user by the FortiGate unit (authentication
methods can be FSAE, firewall authentication, or NTLM).
Refresh
Stop individual
authentication session
Current Page
To Next Page
