Garmin G3X Touch - Vertical Navigation (VNAV)

Garmin G3X Touch
™
Pilot’s Guide for Certified Aircraft
190-02472-00 Rev. D
80
Flight Instruments
System
Overview
Flight
InstrumentsEIS
CNS
Interface
GPS
Navigation
Flight
Planning
Hazard
Avoidance
Additional
FeaturesAFCSAnnun/AlertsAppendixIndex
Angle of Attack (AOA) System
GDU
(Display Unit)
Pneumatic CAN Bus
GSU 25
Air Data Sensor Unit
GAP 26
Air Data Probe
AOA
Pressure
Pitot
Pressure
Static
Pressure
AOA
2.3 VERTICAL NAVIGATION (VNAV)
CAUTION: Internal VNAV is only a VFR navigation aid and is not intended
for instrument approaches.
NOTE: The VNAV function may be inhibited when FPL Source is set
to 'External' with some external navigators. Refer to the external
navigators pilot's guide for more information.
The Vertical Navigation Page provides settings for the vertical navigation feature.
These settings create a three-dimensional profile from the present location and altitude
to a final (target) altitude at a specified location.
