Garmin G3X Touch
™
Pilot’s Guide for Certified Aircraft
190-02472-00 Rev. D
Appendix A
351
System
Overview
Flight
Instruments EIS
CNS
Interface
GPS
Navigation
Flight
Planning
Hazard
Avoidance
Additional
Features AFCS Annun/Alerts Appendix Index
SECTION 11 APPENDICES
APPENDIX A: DATA FIELD OPTIONS
DATA BAR FIELD OPTIONS
Data Bar Field Definition
AGL - Height Above Ground Level
Height Above Ground Level. This field will
display dashes when below a specified AGL.
BRG - Bearing to Waypoint
The compass direction from the present position
to the next waypoint.
CABIN - Cabin Altitude
Current pressure altitude of aircraft cabin
(Requires a compatible CO detector)
CLG - Climb Gradient
Current climb gradient (climb rate divided by
groundspeed) in percent.
CLM - Climb Gradient (ALT/NM)
Current climb gradient (climb rate divided by
groundspeed) in altitude per nautical mile.
CO -Carbon Monoxide (PPM)
Displays current carbon monoxide level in
parts per million. (Requires a compatible CO
detector.)
DA - Density Altitude
Pressure Altitude adjusted for non-standard
temperature.
DIST - Distance to Waypoint
The distance to the next waypoint in the Active
Flight Plan.
DISTD - Distance to Destination
Waypoint
The distance to the destination waypoint in the
Active Flight Plan.
DTK - Desired Track
The desired course between the active “from”
and “to” waypoints.
ECO - Fuel Economy
This value is calculated by dividing the current
ground speed by the current fuel flow.
EDR - Fuel Endurance
This value is obtained by dividing the amount
of fuel on board by the current fuel flow
(endurance to empty - no reserve included).
