MAX DISPLAYED FIELD COUNT (GDU 460 ONLY)
Used to select the maximum number (1-8) of available data boxes shown on the
Data Bar.
DATA FIELDS
Refer to the Annunciations and Alerts Section for a list of available Data Bar Field
options.
Changing the information shown in the Data Bar fields:
1) Press the MENU Key twice.
2) Touch Setup > Data Bar > Data Fields.
3) Touch one of the Data Bar fields.
4) Touch a new data field from the list.
GENERAL DISPLAY INFORMATION
BACKLIGHT SETTINGS
The Backlight Intensity (display brightness) can be set to ‘Manual’, ‘Light Bus’, or
‘Photo Cell’. With ‘Manual’ selected, the pilot can manually adjust the desired backlight
intensity. After each power cycle the Backlight Intensity is set to the default, which is
configurable. Refer to the G3X Touch Installation Manual for more information.
EIS DISPLAY LOCATION (OPTIONAL)
In Configuration Mode the ‘EIS Display Location’ setting can be set to one of the
following:
• AUTO—Displays the EIS Strip on the MFD, or on the PFD if the MFD is not
displayed.
• PFD—Always displays the EIS Strip on PFD .
• User Selected—Enables the user to choose between ‘AUTO’ and ‘PFD’ via the
Display Setup menu.
For more information on how to enable the ‘EIS Display Location’ setting in
Configuration Mode refer to the G3X Touch Installation Manual.
