Garmin G3X Touch Pilot's Guide

Garmin G3X Touch
™
Pilot’s Guide for Certified Aircraft
190-02472-00 Rev. D
224
Hazard Avoidance
System
Overview
Flight
InstrumentsEIS
CNS
Interface
GPS
Navigation
Flight
Planning
Hazard
Avoidance
Additional
FeaturesAFCSAnnun/AlertsAppendixIndex
TRAFFIC PRIORITIZATION
The G3X Touch supports multiple traffic receivers and automatically prioritizes these
devices.
The following are the traffic receivers in order of priority:
- TAS/TCAS I (e.g., GTS or non-Garmin) configured with a GTX 345/345R/45R device.
- GTS 8XX device
- GTX 345/345R, GNX
™
375 devices
- GDL device receiving both air-to-air and TIS-B
- GTX 330ES device receiving TIS-A
- GDL device receiving only air-to-air
The G3X Touch is capable of device switching in the event that a device becomes
unavailable.
TRAFFIC INFORMATION SERVICE (TIS-A) (OPTIONAL)
NOTE: Refer to Appendix E for general information regarding Traffic Informa-
tion Service (TIS-A).
SYSTEM STATUS
The traffic system status is annunciated in the upper right corner of the Map Page.
System Status Traffic Icon
Operating
No Traffic Data Available
If a Traffic Icon is not displayed, check the Map Page range and/or
the Traffic Display Range on the Map Set Up menu.
Traffic Modes

Garmin G3X Touch Specifications

General

Power Input	10-32 VDC
Touchscreen	Yes
Built-in GPS	Yes
AHRS	Yes
Air Data Computer	Yes
Aviation Database	Yes
Terrain Awareness	Yes
Operating Temperature	-20°C to +55°C
Display Size	10.6 inches
Display Type	LCD
Connectivity	Wi-Fi, Bluetooth, USB, RS-232, CAN bus
Engine Monitoring	Yes
Autopilot Compatibility	Yes
Traffic Awareness	Yes
Weather Data	Yes
