Garmin G3X Touch Pilot's Guide

Garmin G3X Touch
™
Pilot’s Guide for Certified Aircraft
190-02472-00 Rev. D
346
Annunciations & Alerts
System
Overview
Flight
InstrumentsEIS
CNS
Interface
GPS
Navigation
Flight
Planning
Hazard
Avoidance
Additional
FeaturesAFCSAnnun AlertsAppendixIndex
ELECTRICAL CONTROL SYSTEM ANNUNCIATION
Annunciation Description
ECS FAIL
The Electrical Control System (GAD 27) has failed. The landing light
wig-wag and backup power to the PFD may no longer function.
Electrical Control System Alerts
TERRAIN ANNUNCIATIONS
In addition to the Terrain Pop-up Alert in the lower left corner of the page, terrain
and obstacle annunciations appear on the PFD in the upper left corner of the Attitude
Indicator. Refer to the Hazard Avoidance Section for more details.
TRAFFIC ANNUNCIATIONS
The G3X Touch displays traffic symbolically on the Map Page, and the Traffic Warning
Window (Inset Map). Refer to the Hazard Avoidance Section and the Annunciations
and Alerts section for more details.
AHRS ALERTS (OPTIONAL)
REVERSION ALERTS
If a Garmin G5 standby flight display is present and the primary ADAHRS source
is unavailable, the messages ‘AHRS REVERT’ and ‘ADC REVERT’ will appear. These
messages indicate the PFD has reverted to using attitude and air data from the standby
flight display instead of a dedicated ADAHRS unit.

Garmin G3X Touch Specifications

General

Power Input	10-32 VDC
Touchscreen	Yes
Built-in GPS	Yes
AHRS	Yes
Air Data Computer	Yes
Aviation Database	Yes
Terrain Awareness	Yes
Operating Temperature	-20°C to +55°C
Display Size	10.6 inches
Display Type	LCD
Connectivity	Wi-Fi, Bluetooth, USB, RS-232, CAN bus
Engine Monitoring	Yes
Autopilot Compatibility	Yes
Traffic Awareness	Yes
Weather Data	Yes
