Garmin G3X Touch
™
Pilot’s Guide for Certified Aircraft
190-02472-00 Rev. D 317
AFCS
System
Overview
Flight
Instruments EIS
CNS
Interface
GPS
Navigation
Flight
Planning
Hazard
Avoidance
Additional
Features AFCS Annun/Alerts Appendix Index
GO AROUND (GA) AND TAKEOFF (TO) MODES
Go Around and Takeoff modes are coupled pitch and roll modes and are annunciated
as both the vertical and lateral modes when active. In these modes, the flight director
commands a constant set pitch attitude and keeps the wings level. The GA Switch
is used to activate both modes. The mode entered by the flight director depends on
whether the aircraft is on the ground or in the air.
Takeoff Mode provides an attitude reference during rotation and takeoff. This mode
can be selected only while on the ground by pushing the TO/GA Button. The flight
director Command Bars assume a wings-level, pitch-up attitude.
Pressing the TO/GA Button while in the air activates the flight director in a wings-
level, pitch-up attitude, allowing the execution of a missed approach or a go around.
9.3 LATERAL MODES
The following table lists the lateral modes and respective control(s) and annunciation.
Refer to the vertical modes section for information regarding Takeoff and Go Around
Modes.
Lateral Mode Description Control Annunciation
Roll Hold
Holds the current aircraft roll
attitude or rolls the wings level,
depending on the commanded
bank angle
(default) ROL
Heading Select
Captures and tracks the Selected
Heading
HDG Key
(GMC
507)
or
HDG
HDG
Track
Captures and tracks the Selected
Ground Track
TRK Key
(GMC 507)
or
TRK
TRK
