8.2 SAFETAXI
®
SafeTaxi is an enhanced feature that gives greater map detail when viewing airports
at close range. When viewing at ranges close enough to show the airport detail, the
map reveals taxiways with identifying letters/numbers, runway incursion “Hot Spots”,
and airport landmarks including ramps, buildings, control towers, and other prominent
features. Resolution is greater at lower map ranges. The SafeTaxi feature can be seen
on the Map Page and the Waypoint Page
Designated Hot Spots are recognized at airports with many intersecting taxiways
and runways, and/or complex ramp areas. Airport Hot Spots are outlined to caution
pilots of areas on an airport surface where positional awareness confusion or runway
incursions happen most often. Hot Spots are defined by magenta outlines.
During ground operations the aircraft’s position is displayed in reference to taxiways,
runways, and airport features. When panning over the airport, features such as runway
holding lines and taxiways are shown at the cursor.
SafeTaxi Depiction on the Map Page
Airport Hot
Spot Outline
Taxiway Identi-
fication
Enabling/disabling SafeTaxi:
1) From the Map Page press the MENU Key.
2) Touch Set Up Map.
3) Touch and drag the tabs to scroll.
4) Touch the Airport Tab.
5) Touch and drag to scroll down
