The information in this section applies to the following maps unless otherwise noted:
• All Map Pages (MAP)
• Waypoint Page (WPT)
• All Nearest Pages (NRST)
• Active Flight Plan Page
• Direct-to Window
MAP PAGE SETUP
MAP ORIENTATION
Maps are shown in one of three different orientation options, allowing flexibility
in determining aircraft position relative to other items on the map (North Up) or for
determining where map items are relative to where the aircraft is going (Track Up), or
desired track up (DTK UP).
• North Up aligns the top of the map display to north (default setting).
• Track Up aligns the top of the map display to the current ground track.
• Desired Track (DTK) Up aligns the top of the map display to the desired course.
NOTE: Map orientation can only be changed on the Map Page. Any other
pages that show navigation data reflect the orientation selected for the Map
Page.
Changing the Navigation Map orientation:
1) With the Map Page displayed, press the MENU Key.
2) Touch Set Up Map.
3) Under the ‘General’ Tab, touch and drag to scroll to the Orientation field.
4) Touch .
5) Touch North Up, Track Up, or DTK Up.
