AUTOMATIC FLIGHT CONTROL SYSTEM
The G3X Touch can also communicate with the Garmin GFC 500. With the AFCS
configured, the G3X Touch issues pitch and roll steering commands to the autopilot.
Refer to Section 9 (AFCS) for more information.
1.2 DISPLAY OVERVIEW
Left Knob Right KnobNearest
Button
Direct-to
Button
SD Card
Slot
Menu
Button
Back
Button
Bezel Overview (GDU 460)
