SYSTEM STATUS MESSAGES
Message Comments
[LRU name] hardware fault The specified LRU has a hardware fault and
requires service.
Config module error The GDU
™
has encountered a problem writing
to/from the config module The G3X Touch
™
system should be serviced.
Config module missing The PFD config module is not connected.
[LRU name] using backup RS-232
interface
The specified LRU was wired for both CAN and
RS-232 communication paths, and the device is
not communicating via CAN.
[LRU name] temperature out of
spec
The specified LRU is either too hot or too cold.
Check installation and/or hardware for cause.
[LRU name] power supply fault The specified LRU’s internal power supply has
a problem or the input voltage is out of the
required specifications.
AHRS not calibrated The specified AHRS is either not calibrated
or requires the post installation calibration
procedure. See G3X Touch installation manual
for calibration instructions.
AHRS magnetometer not
calibrated
The specified AHRS is either not calibrated or
requires the magnetometer post installation
calibration procedure. See G3X Touch
installation manual for calibration instructions.
AHRS not receiving
magnetometer data
The specified AHRS is not receiving
magnetometer data. Check installation and
configuration.
AHRS not receiving air data The specified AHRS is not receiving air data.
Check installation and configuration.
AHRS not receiving GPS data The specified AHRS is not receiving any or any
useful GPS information. Check installation and
configuration.
