Garmin G3X Touch Pilot's Guide

Garmin G3X Touch
™
Pilot’s Guide for Certified Aircraft
190-02472-00 Rev. D 105
CNS Interface
System
Overview
Flight
Instruments EIS
CNS
Interface
GPS
Navigation
Flight
Planning
Hazard
Avoidance
Additional
Features AFCS Annun/Alerts Appendix Index
3) Touch the User Tab.
4) Touch Edit User Frequencies.
5) Touch Delete.
6) Touch Yes.
4.7 AUDIO PANEL
NOTE: The audio panel information in this section pertains only to G3X
systems configured with a GMA 245R. Screenshots and descriptions
may differ from actual display function depending upon configuration.
When configured with a compatible audio panel, touching the Audio Box on the
CNS Data Bar will display the Audio/Intercom Page. The Audio/Intercom Page allows
selection of four separate tabs, these are the Radios, Intercom, Phone & Media, and
Music Input tabs. The Audio Box can be configured for Normal or Minimized display
format, (Audio Only format may be displayed as determined by available space on the
CNS Data Bar).
Audio/Intercom
Page Select
Audio Box on CNS Data Bar
MIC/COM
Select
Audio Box

Garmin G3X Touch Specifications

General

Power Input	10-32 VDC
Touchscreen	Yes
Built-in GPS	Yes
AHRS	Yes
Air Data Computer	Yes
Aviation Database	Yes
Terrain Awareness	Yes
Operating Temperature	-20°C to +55°C
Display Size	10.6 inches
Display Type	LCD
Connectivity	Wi-Fi, Bluetooth, USB, RS-232, CAN bus
Engine Monitoring	Yes
Autopilot Compatibility	Yes
Traffic Awareness	Yes
Weather Data	Yes
