Garmin G3X Touch
™
Pilot’s Guide for Certified Aircraft
190-02472-00 Rev. D
268
Additional Features
System
Overview
Flight
InstrumentsEIS
CNS
Interface
GPS
Navigation
Flight
Planning
Hazard
Avoidance
Additional
FeaturesAFCSAnnun/AlertsAppendixIndex
8.4 FLITECHARTS
®
WARNING: Do not use the approach information provided by the VFR naviga-
tion database residing within the G3X Touch as a means of navigating any
instrument approach. The G3X Touch VFR navigation database is limited to
present only the waypoints for the final approach leg of a published procedure.
These waypoints and associated course line are made available for monitoring
purposes only.
FliteCharts resemble the paper version of National Aeronautical Charting Office
(NACO) terminal procedures charts. The charts are displayed with high-resolution
and in color for applicable charts. FliteCharts database subscription is available from
Garmin. Available data includes:
• Arrivals (STAR)
• Departure Procedures (DP)
• Approaches
• Airport Diagrams
• Takeoff Minimums
• Alternate Minimums
The geo-referenced aircraft position is indicated by an aircraft symbol displayed on
the chart when the current position is within the boundaries of the chart. An aircraft
symbol may be displayed within an off-scale area depicted on some charts.
The figure below shows examples of off-scale areas, indicated by the grey shading.
Note, these areas are not shaded on the published chart. These off-scale areas appear
on the chart to convey supplemental information. However, the depicted geographical
position of this information, as it relates to the chart planview, is not the actual
geographic position. Therefore, when the aircraft symbol appears within one of these
areas, the aircraft position indicated is relative to the chart planview, not to the off-
scale area.
