Garmin G3X Touch Pilot's Guide

Garmin G3X Touch
™
Pilot’s Guide for Certified Aircraft
190-02472-00 Rev. D
290
Additional Features
System
Overview
Flight
InstrumentsEIS
CNS
Interface
GPS
Navigation
Flight
Planning
Hazard
Avoidance
Additional
FeaturesAFCSAnnun/AlertsAppendixIndex
8.11 CARBON MONOXIDE (CO) DETECTOR
(OPTIONAL)
NOTE: Refer to the approved Pilot’s Operating Handbook (POH) for emergency
procedures.
If a carbon monoxide (CO) detector is installed, the current CO measurement in parts
per million (ppm) can be displayed in the Data Bar.
Displaying the current CO measurement in the Data Bar field:
1) Press the MENU Key twice.
2) Touch Setup > Data Fields > Change....
3) Touch one of the Data Bar fields.
4) Touch CO PPM from the list of data fields.
Carbon monoxide levels are recorded in the G3X Touch data log file as well.
Data Bar
CO Measurement In PPM
In the event high CO levels are detected, the CO data field will flash yellow (if
displayed) and a CO LEVEL CAS Message is displayed.
CO Data Bar Field (High CO) High CO CAS Message (PFD)
If the carbon monoxide (CO) detector is inoperative, a CO FAIL CAS Message is
displayed.
CO Detector is Inoperative

Garmin G3X Touch Specifications

General

Power Input	10-32 VDC
Touchscreen	Yes
Built-in GPS	Yes
AHRS	Yes
Air Data Computer	Yes
Aviation Database	Yes
Terrain Awareness	Yes
Operating Temperature	-20°C to +55°C
Display Size	10.6 inches
Display Type	LCD
Connectivity	Wi-Fi, Bluetooth, USB, RS-232, CAN bus
Engine Monitoring	Yes
Autopilot Compatibility	Yes
Traffic Awareness	Yes
Weather Data	Yes
