Garmin G3X Touch
™
Pilot’s Guide for Certified Aircraft
190-02472-00 Rev. D 127
CNS Interface
System
Overview
Flight
Instruments EIS
CNS
Interface
GPS
Navigation
Flight
Planning
Hazard
Avoidance
Additional
Features AFCS Annun/Alerts Appendix Index
MUSIC EFFECTS
The Music 1, Music 2, and Bluetooth sections have music effect selections as follows:
•
Bass Boost - Available settings are None, Medium, and High
•
Equalizer - Available settings are None, Rock, Classical, and Pop
4.8 REMOTE TRANSPONDER INTERFACE
(OPTIONAL)
The G3X Touch is capable of interfacing with several remote transponders
providing Mode S interrogation and reply capabilities. Selective addressing or Mode
Select (Mode S) capability includes the following features:
•
Level-2 reply data link capability (used to exchange information between aircraft
and ATC facilities)
• Surveillance identifier capability
• Flight ID (Flight Identification) reporting - The Mode S Transponder reports
identification as either the aircraft registration or a unique Flight ID.
• Altitude Reporting
• Airborne status determination
• Transponder capability reporting
• Mode S Enhanced Surveillance (EHS) requirements
• Acquisition squitter - Acquisition squitter, or short squitter, is the transponder
24 bit identification address. The transmission is sent periodically, regardless
of the presence of interrogations. The purpose of the acquisition squitter is to
enable Mode S ground stations and aircraft equipped with a Traffic Avoidance
System (TAS) to recognize the presence of Mode S-equipped aircraft for selective
interrogation.
